The Signal Analysis Methods of Ultrasonic Guided Wave Propagation Modes in Thin Plate
-
摘要: 根据兰姆波在薄板中传播的频散特性，针对超声检测中获取的检测信号，采用双重时间尺度对比的方式，对兰姆波模态进行分析。采用半解析有限元法绘制各向同性自由铝板中兰姆波频散曲线，选用合适的超声换能器获得兰姆波在铝板不同位置的多模态传播信号。在兰姆波整体传播时间尺度下，用二维傅里叶变换对全部数据进行分析，确定了其模态及能量分布，再经过滤波降噪，利用Hilbert-Huang变换分离并精确分辨单个信号内叠加的不同模态的时间尺度。结果表明，上述方法可以识别兰姆波导波模态并获得较高的时间分辨率。
-
关键词:
- 兰姆波 /
- 信号处理 /
- 半解析有限元 /
- 二维傅里叶变换 /
- Hilbert-Huang变换
Abstract: In this paper, the modal analysis of Lamb wave was made according to the dispersion properties of its propagation in the thin plateby comparing the two time scales of the signal collected in ultrasonic testing. Based on the dispersion curves of Lamb wave drawn by semi analytical finite element method in the isotropic free aluminum,suitable ultrasonic transducers were selected to obtain modal signal propagation of Lamb wave in aluminum plate in different positions. In the overall time scale of Lamb wave, all the data were analyzed by two-dimensional Fourier transform and the modal and energy distribution would be identified. In the other time scale, the Hilbert-Huang transform was used to separate and distinguish the different modes accurately that were superimposed in a single signal after a reasonable filtering and noise reduction. The results show that we can analyze and compare the signal data of Lamb wave acquired from detection and identify the guided wave mode and get higher time resolution with the above method. -
-
[1] 刚铁,刘强.薄板结构中Lamb波的检测与仿真[J].无损检测, 2013,35(7):24-28. [2] 司祯祯.傅里叶变换与小波变换在信号去噪中的应用[J].电子设计工程,2011,19(4):155-157. [3] 应崇福,张守玉,沈建中.超声在固体中的散射[M].北京:国防工业出版社,1994. [4] 禹化民,王维斌,吕小青,等.储罐底板缺陷兰姆波检测的影响因素[J].无损检测,2015,37(7):19-24. [5] 张博南,霍宇森,吴迪,等.钛合金薄板Lamb波检测的有限元分析[J].无损检测,2015,30(10):64-68. [6] 张海燕,吕东辉,刘镇清.二维傅里叶变换在Lamb波模式识别研究中的应用[J].振动、测试与诊断,2004,24(1):23-26. [7] HUANG N,SHEN Z, LONG S R,et al.The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-stationary time series analysis[J]. Proceedings of the Royal Society A:Mathematical, Physics and Engineering Sciences, 1998, 454(1971):903-995.
[8] YANG J N, LEI Y,HUANG N.Damage identification of civilengineering structures using Hilbert-Huang transform[C]//Proceedings of the 3rd International Workshop on Structural Health Monitoring,New York:[s.n.],2001:544-545.
[9] 郑祥明,王杜,杨齐,等.基于改进HHT的多模式Lamb波信号的时频分析[J].无损检测,2008,30(5):271-275. [10] 马庆增,王瑞璇,邹宝诚,等.基于HHT重构信号的超声降噪方法[J].无损检测,2014,36(1):37-40. [11] 张海燕,于建波,孙修立,等.HHT在Lamb波检测信号分析中的应用[J].振动、测试与诊断,2010,30(3):223-226.
