Development of EMAT Based Axial Load Measurement System for In-service Bolts
-
摘要: 为解决在役螺栓轴力测量的技术难题，根据基于波型转换的单传感器螺栓轴力超声测量原理，研制出一套在役螺栓轴力电磁超声测量系统。详细介绍了电磁超声探头、主机和测量软件等系统的组成部分。实验室和现场试验证明,该系统能够用于在役螺栓轴力测量，测量相对误差不超过10%。该系统采用电磁超声非接触耦合，避免了耦合剂影响，测量结果具有良好的稳定性，为螺栓轴力控制提供了一种新的技术手段。Abstract: To solve the technical problems of the axial load measurement of in-service bolts, the measurement system for the axial load of in-service bolts using the electromagnetic acoustic transducers is developed according to the principle of axial load measurement based on mode conversion. It consists of electromagnetic acoustic transducer, host, and software. Laboratory and field experiments indicated that the system could be used in axial load measurement of in-service bolts and the measuring relative error was less than 10%. The advantage of the system is that the electromagnetic acoustic transduction is adopted to obtain the good stability and to avoid the effect of couplant in the traditional piezoelectric transduction. In the meanwhile, a new technical means for the bolt axial load control is also provided.
-
-
[1] 汤生虎,陈爱东,许成明,等.重庆朝天门长江大桥高强度螺栓试验研究［J］.中国港湾建设,2012(2):25-30. [2] 吴兴红. 南京大胜关长江大桥高强度螺栓试验概述［J］. 铁道建筑, 2010(3): 1-3. [3] 陆晓峰, 顾伯勤, 涂善东. 高温螺栓法兰连接研究进展［J］. 压力容器, 2004, 21(12): 34-42. [4] 初泰安. 螺栓拧紧方法及预紧力控制［J］. 石化技术, 2005, 11(3): 42-45. [5] JOHNSON G C, HOLT A C, CUNNINGHAM B. Ultrasonic method for determining axial stress in bolts［J］. Journal of Testing & Evaluation, 1986, 14(5): 253-259. [6] CHAKI S, CORNELOUP G, LILLAMAND I, et al. Combination of longitudinal and transverse ultrasonic waves for in situ control of the tightening of bolts［J］. J Press Vess-T ASME, 2007, 129(3): 383-390. [7] 杜刚民, 李东风, 曹树林, 等. 螺栓轴向应力超声测量技术［J］. 无损检测, 2006, 28(1): 20-22. [8] 何存富,吴克成,石建中,等.大桥螺栓施拧轴力的超声测量［J］.实验力学,1994,9(1)：74-78. [9] 朱士明, 肖明正，卢杰, 等. 超声波高温螺栓应力监测仪的研制［J］. 同济大学学报:自然科学版, 1991, 19(4): 433-439. [10] HIRAO M, OGI H. Emats for science and industry［M］. Dordrecht: Kluwer Academic Publishers, 2003:245-260.
