涡流检测冷凝器薄壁钛管管壁凹陷程度的评估方法

详细信息

Evaluation Method of Condensor Thin-walled Titanium Tube Dent Degree by ET Testing

摘要: 目前普遍采用内穿涡流检测法对核电机组冷凝器的薄壁换热钛管进行在役期间检测, 而管壁凹陷则是在役期间最常见的管壁损伤类型。对特制的凹陷样管进行了涡流检测, 将信号幅值与凹陷面积进行了对比。结果显示: 信号幅值与管壁凹陷面积大致呈线性关系, 并据此提出了一种用涡流检测幅值来评估管壁凹陷程度的定量方法。
- 涡流检测 /
- 管壁凹陷 /
- 信号幅值 /
- 凹陷面积 /
- 标定方法
Abstract: Thin-walled titanium tube is widely used as heat-exchange tube in nuclear power plant, and nowadays the inner ET testing is wildly used in titanium tube in-service inspection. In this paper we tested the sample tube with dents by ET tester, and made a comparison between the results, and then we found the linear relationship between signal amplitude and the dent area. Based on that, we provide a method to evaluate the dent degree of tubes quantitatively.
- ET /
- Tube dent /
- Signal amplitude /
- Dent area /
- Evaluate quantitatively

[1]	李景和.海水作为冷却介质的汽轮机凝汽器泄漏原因及对策［J］.东北电力技术, 2006, 27(3): 41-44.
[2]	陈海峰.大型热交换器用钛管的质量控制［J］.电站辅机, 2008, 106(3): 30-31.
[3]	余存烨.海水凝汽器传热管的选材与防护［J］.腐蚀与防护, 1997, 18(3): 12-15.
[4]	葛炼伟, 郭韵, 丁有元.核电厂高压加热器传热管涡流检测及缺陷产生机理分析［J］.无损检测, 2014, 36(1): 74-76.
[5]	袁建中, 叶琛, 刘一舟.热交换器传热管的涡流检测及失效分析［J］.腐蚀科学与防护技术, 2010, 22(1): 77-78.
[6]	李志刚, 汪德良, 孙本达.薄壁钛管的涡流检测［J］.无损检测, 1995, 17(5): 132-134.
[7]	张才良, 胡达群.涡流检测对比试样的作用［J］.无损检测, 2013, 35(3): 38-41.
[8]	徐可北, 周俊华.涡流检测［M］.北京: 机械工业出版社, 2004.
[9]	李小亭, 沈功田.压力容器无损检测——涡流检测技术［J］.无损检测, 2004, 26(8): 411-416.
