基于压电阻抗法的结构损伤检测技术进展

张玉祥; 张鑫; 陈家照; 李知佳

doi:10.11973/wsjc201601019

基于压电阻抗法的结构损伤检测技术进展

第二炮兵工程大学, 西安 710025

基金项目:

国家自然科学基金资助项目(51275517,51105364)

详细信息

作者简介:
张玉祥(1963- ), 男, 博士生导师, 主要从事动力系统检测与故障诊断、系统综合性能分析与评估方面的研究工作。

中图分类号: TG115.28
计量
- 文章访问数: 10
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2015-05-19
- 刊出日期: 2016-01-09

Development on Detecting Technique of Structure Damage Based on EMI

摘要

摘要: 为了实现结构损伤的快速在线检测, 研究基于压电阻抗(EMI)法的无损检测技术十分必要。总结了国内外在EMI方面的研究进展, 全面概括了应用EMI的单位和个人在此方面取得的成果, 并介绍了基于EMI检测损伤的经验及成熟度, 对后续开展基于EMI的结构检测具有指导意义。
- 损伤检测 /
- 压电阻抗 /
- 脱粘
Abstract: In order to resolve the problem of the rapid on-line detection of structural damage, studying the research development of nondestructive testing technology based on the EMI is necessary. This paper systematically summarizes the research progress of EMI method in recent years at home and abroad, comprehensively sums up the achievements achieved by units and individuals who apply the EMI, and introduces the experience and maturity of damage detection based on EMI in various damage cases, which will have guiding significance on the structure testing based on EMI hereafter.
- Damage detecting /
- EMI /
- Debonding
