The Influence of the Elbow Surface of Boiler Tube on Eddy Current Probe′s Impedance
-
摘要: 对锅炉管弯头进行涡流检测时,弯头复杂的曲面结构会对检测结果的准确性产生影响, 故分析弯头曲面对探头阻抗的影响具有重要意义。通过建立放置式涡流探头检测不锈钢弯头的ANSYS有限元模型, 分析了弯头弯曲半径及周向检测位置的变化对探头反射阻抗的影响, 并进行了试验验证。结果表明: 弯曲半径增大时, 反射阻抗幅值的变化量增大, 相位则减小; 探头从弯头内侧往外侧移动时, 反射阻抗幅值的变化量逐渐减小, 而相位则增大。Abstract: The complex structure of elbow surface is the main difficulty which hampers eddy current technique being conducted on boiler tube elbow. Therefore, in order to improve the detection accuracy, it is of great significance to study the influence of the elbow surface on probe’s impedance. In this paper, the finite element model of a pancake probe-coil over a stainless steel tube elbow was established. Influences of the variations of the pipe’s curvature radius and the probe′s circumferential detecting position on the probe’s reflected impedance were respectively studied. Also, an experiment validation of the simulation was conducted. The results are as follows: (i) as the radius of curvature increases, the variation of the reflected impedance amplitude increases but the impedance phase decreases. (ii) as the probe is moved from the inner side of the elbow to the outer side, the variation of the reflected impedance amplitude decreases but the impedance phase increases.
-
Keywords:
- Eddy current testing /
- Boiler tube /
- Elbow /
- Impedance /
- Finite element method
-
-
[1] 张国华, 李敬高. 奥氏体不锈钢应力腐蚀分析研究［J］. 焊接技术,2002, 31(6): 53-54. [2] 李萌, 胡斌. 奥氏体不锈钢中马氏体含量的相关无损检测方法［J］. 无损检测, 2014, 36(7): 19-24,66. [3] 沈丁杰, 邹建伟, 胡彬. 锅炉受热面奥氏体不锈钢管弯头表面裂纹涡流检测技术研究［J］. 湖南电力,2011, 31(3):5-7. [4] 刘金秋.奥氏体锅炉管内壁氧化皮脱落堆积测量技术研究［D］. 济南: 山东大学, 2011. [5] TAKAGI T. Benchmark models of eddy current testing for steam generator tube: experiment and numerical analysis［J］. International Journal of Applied Electromagnetics in Materials, 1994, 5(3): 149-162. [6] 张玉华, 孙慧贤, 罗飞路. 小曲率半径弧面涡流检测中探头提离干扰的抑制方法［J］. 中国电机工程学报, 2009, 29(27): 126-132. [7] 宋林, 杨随先, 李小建, 等. 曲面零件裂纹缺陷脉冲涡流热成像检测的仿真［J］. 无损检测, 2012, 34(9): 39-41. [8] GILLES-PASCAUD C, DECITRE J M, VACHER F, et al. Eddy current flexible probes for complex geometries［J］. Review of Progress in Quantitative Nondestructive Evaluation, 2005, 25: 399-406. [9] SHEIRETOV Y, GRUNDY D, ZILBERSTEIN V, et al. MWM-array sensors for in situ monitoring of high-temperature components in power plants［J］. Sensors Journal, IEEE, 2009, 9(11): 1527-1536. [10] 丁天怀, 陈祥林. 用于测量曲面间隙的电涡流传感器线圈［J］. 清华大学学报: 自然科学版, 2006, 46(2): 180-183. [11] GB/T 28075-2012无损检测 脉冲涡流检测方法［S］.
