Impedance Matching Optimization of Guided Wave Magnetostrictive Sensor for Large-Diameter Pipes
-
摘要: 针对基于磁致伸缩式纵向超声导波传感器的管道无损检测问题,介绍了磁致伸缩式纵向超声导波传感器的检测原理及其结构.在此基础上,对接收传感器与接收源之间的阻抗匹配问题进行了讨论,阐述了实现阻抗匹配的条件与方法,并且通过理论计算得到最佳匹配条件与匹配电路的最佳电容.最后,设计了验证试验,验证了阻抗匹配问题的存在,讨论了阻抗匹配角、匹配电容值与导波信号幅值之间的关系,并且利用试验方法得到了真实条件下匹配电路的最佳电容值.Abstract: Aiming at the problems of nondestructive testing of pipelines based on longitudinal guided wave magnetostrictive sensor,in this article,the testing principle and structure of the longitudinal guided wave magnetostrictive sensor was introduced.Based on it,the problem of the impedance matching between the receiving transducer and the receiving source was discussed deeply.The conditions of implementation and methods of impedance matching are elaborated.Optimal matching condition and the optimal capacitor of the matching circuit is obtained from theoretical calculations.Finally,experiment was designed to verify the existence of the problems of impedance matching,and the relationships among the impedance matching angle,the matching capacitance and the guided wave signal amplitude was discussed,and the best capacitance value of matching circuit under real conditions was obtained by experimental method.
-
-
[1] 王悦民,谢俊丽,刘东.基于磁致伸缩效应的导波无损检测技术研究进展[J].无损检测,2007,29(5):280-284. [2] 柯岩,武新军,康宜华,等.基于磁致伸缩效应的钢管导波检测可行性[J].无损检测,2007,29(3):113-116. [3] 武新军,徐江,沈功田.非接触式磁致伸缩导波管道无损检测系统的研制[J].无损检测,2010,23(3):166-170. [4] 金建华,申阳春.一种用于管道检测的磁致伸缩式周向超声导波传感器[J].传感技术学报,2004(4):576-579. [5] 柯岩.基于磁致伸缩导波的钢管无损检测实验研究[D].武汉:华中科技大学,2006:37-42. [6] 程涛.管道裂纹磁致伸缩导波检测传感器研制与开发[D].武汉:湖北工业大学,2012:37-51. [7] 王博文,黄淑瑛,黄文美.磁致伸缩材料与器件[M].北京:冶金工业出版社,2008:1-6. [8] 吴斌,刘秀成,何存富.兆赫兹纵向模态磁致伸缩传感器的设计及其在钢绞线中的试验研究[J].机械工程学报,2011,47(22):148-153. [9] 龙毅,张正义,李守卫.新型功能磁性材料及其应用[M].北京:机械工业出版社,1997:58-60. [10] 郭继红.关于阻抗匹配问题的分析[J].辽宁大学学报:自然科学版,2001,28(3):257-258.
