静载拉伸过程中三维磁记忆信号的变化特征

李冲冲; 董丽虹; 王海斗; 王慧鹏; 李国禄

doi:10.11973/wsjc201508002

静载拉伸过程中三维磁记忆信号的变化特征

1.
河北工业大学材料科学与工程学院, 天津 300130
2.
装甲兵工程学院装备再制造技术国防科技重点实验室, 北京 100072

基金项目:

国家“973”计划资助项目(2011CB013401)

国家杰出青年科学基金资助项目(51125023)

详细信息

作者简介:
李冲冲(1989-),男,硕士研究生,主要研究方向为金属磁记忆检测技术.

中图分类号: TG115.28
计量
- 文章访问数: 4
- HTML全文浏览量: 1
- PDF下载量: 8
出版历程
- 收稿日期: 2015-01-08
- 刊出日期: 2015-08-09

The Characteristics of Three-dimensional Magnetic Memory Signals during Static Tension Process

摘要

摘要: 基于三维磁敏传感单元,研究了不同载荷激励下FV520B钢试件表面三维自发射漏磁信号的变化及分布特征,分析了磁记忆信号的不同特征参量,并探讨了该特征参量与轴向应力之间的相关性.结果表明:三维弱磁信号在加载阶段和断裂后均呈现不同的变化特征,根据断裂后激变信号特征可对失效部位进行准确定位;磁记忆信号特征参量与外加应力之间存在一定的相关性,Bxave和KBz特征量与外加应力之间近似呈线性变化,根据该特征量的变化可以判断试件承受的工作应力;根据特征值KBz和Byave随应力的变化关系可以区分试件的弹、塑性变形阶段;三维磁记忆技术可为复杂零构件的损伤判定提供指导.
- 三维磁记忆信号 /
- 静载拉伸 /
- 特征参量 /
- 外加应力
Abstract: Based on the three-dimensional magnetic sensor,the variation characteristics of three-dimensional self-emitting magnetic signals of FV520B steel were studied under different tensile loads,and different characteristic parameters of magnetic signals were analyzed and the correlations between parameters and applied stress were explored.The results indicated that three-dimensional magnetic memory signals showed different variation features during tensile process and fracturing,and could accurately locate the site of failure according to the signal changes.Meanwhile,there was a certain correlation between the parameters and applied stress,the relationship between applied stress and parameters of Bxave and KBz was approximately linear and the applied stress of the specimens could be predicted based on the eigenvalues.The elastic and plastic deformation stages could be distinguished according to the relationship between stress and parameters of KBz and Byave.Three-dimensional magnetic memory technology would provide guidance on how to identifythe damage of complex components.
- Three-dimensional magnetic memory signals /
- Static tension /
- Characteristic parameters /
- Applied stress

HTML全文

参考文献(16)

[1]	任吉林,林俊明.金属磁记忆检测技术[M].北京:中国电力出版社,2000.
[2]	DOUBOV A A.Diagnostics of steam turbine disks using the metal magnetic memory method[J].Thermal Engineering,2010,57(1):16-21.
[3]	DOUBOV A A.Development of a metal magnetic memory method[J].Chemical and Petroleum Engineering,2012,47(11):837-839.
[4]	WILSON J,TIAN G Y,BARRANS S.Residual magnetic field sensing for stress measurement[J].Sensors and Actuators,2007,135 (2):381-387.
[5]	ROSKOSZ M,BIENIEK M.Analysis of the universality of the residual stress evaluation method based on residual magnetic field measurements[J].NDT&E International,2013,54(3):63-68.
[6]	ROSKOSZ M,RUSIN A,KOTOWICZ J.The metal magnetic memory method in the diagnostics of power machinery components[J].Journal of Achievements in Materials and Manufacturing Engineering,2010,43(1):362-370.
[7]	李红梅,赵天飞,陈振茂.基于自然磁化现象的损伤定量无损检测方法[J].西安交通大学学报,2011,45(1):58-63.
[8]	任吉林,林俊明,任文坚,等.金属磁记忆检测技术研究现状与发展前景[J].无损检测,2012,34(4):3-11.
[9]	任吉林,王进,范振中,等.一种磁记忆检测定量分析的新方法[J].仪器仪表学报,2010,31(2):431-436.
[10]	陈星,刘昌奎,陶春虎,等.金属材料拉伸损伤的磁记忆表征[J].无损检测,2009,31(5):345-348.
[11]	DOUBOV A A.Diagnostics of steam turbine disks using the metal magnetic memory method[J].Thermal Engineering,2010,57(1):16-21.
[12]	ROSKOSZ M,BIENIEK M.Evaluation of residual stress in ferromagnetic steels based on residual magnetic field measurements[J].NDT&E International,2012 45(1):55-62.
[13]	张卫民,涂青松,殷亮.静拉伸条件下螺纹联接件三维弱磁信号研究[J].北京理工大学学报,2010,30(10):1152-1179.
[14]	梁志芳,李午申,王迎娜,等.金属磁记忆信号的零点特征[J].天津大学学报,2009,39(7):847-850.
[15]	DONG Li-hong,XU Bin-shi,DONG Shi-yun,et al.Variation of stress-induced magnetic signals during tensile testing of ferromagnetic steels[J].NDT&E International,2008,41(3):184-189.
[16]	SHI C L,DONG S Y,XU B S,et al.Metal magnetic memory effect caused by static tension load in a case-hardened steel[J].Journal of Magnetism and Magnetic Materials,2010,322(4):413-416.
