Low-power Technology of Subminiature Ultrasonic Testing System
-
摘要: 介绍了超声检测系统低功耗的实现方案.该系统基于FPGA和ARM平台,采用了模块化层次化的设计思想,重点从硬件和软件两个方面研究了超声检测系统低功耗的实现方法:利用变压器耦合电路实现了收发电路与放大器的隔离,降低了放大器的电压;利用AD分时采样减少了AD采样工作时间,减少系统功耗;利用Linux电源管理功能实现了系统的休眠与唤醒,减少了设备工作时间.经过性能测试表明,提出的三种方法有效地降低了系统的功耗,延长了电池的使用时间,提升了系统的性能,满足设计需求.Abstract: Implement of ultrasonic testing system of low-power consumption is presented in this paper.The system is based on FPGA and ARM platforms,using a modular hierarchical design.This paper focuses on the non-destructive testing methods to achieve low-power systems from both hardware and software:The isolation of transceiver circuit and amplifier by dormancy transformer coupling circuit,which reduces the voltage of the amplifier.Through the AD time-sampling technology,it reduces the working time of AD sampling and the power consumption of the system.The implement of sleep and wake-up of the device by the power management of Linux system shall reduce the time of the device.After the performance tests,it shows that the three methods proposed in this paper effectively reduce the power consumption of the system,prolong the use time of battery,improve the performance of the system and meet the requirements.
-
Keywords:
- Ultrasonic testing /
- Low-power consumption /
- AD sample /
- System sleep
-
-
[1] 胡建垲,张谦琳.超声检测原理和方法[M].合肥:中国科学技术大学出版社,1993:20-29. [2] MEL G.Understanding the linux virtual memory magager[M].Upper Saddle River,New Jersey:Prentice Hall,2004:87-90. [3] JASMIN B,MARK S.C++ GUI Programming with Qt3[M].Upper Saddle River,New Jersey:Prentice Hall,2004:86-94. [4] 许药林,沈祥华,徐大专.超声相控阵成像系统软件设计[J].无损检测,2013,35(4):5-9. [5] 常青龙.基于ARM平台的超声波自动探伤硬件系统的研制[D].南京:南京航空航天大学,2008. [6] ROBERT L.Linux内核设计与实现[M].北京:机械工业出版社,2011:91-106. [7] 马忠梅,李善平,康慨,等.ARM&Linux系统教程[M].北京:北京航空航天大学出版社,2004:13-17. [8] 丁松林,黄丽琴.Qt4图形设计与嵌入式开发[M].北京:人民邮电出版社,2009:327-340.
